Maintenance of automatic paint spraying machine

Automatic paint spraying machine should pay attention to maintenance and maintenance after its use, which can effectively improve its service life. Many customers do not know how to maintain automatic paint spraying machine. Today, the Richfruits automatic paint spraying machine manufacturer will introduce you to How to maintain automatic paint spraying machine.

1. Before using the paint sprayer every day, you should check whether the grounding protection is intact. The grounding wire plays a very important role in protecting the safety of equipment and personnel, and abnormal grounding is not allowed.

2. Before use, you should check whether the oil pipe is leaking, whether the gas pipe is leaking, etc., and if any defects are found, they can be started up and run in time. Check the hose and its connecting parts for leakage.

3. After each shutdown, scrub the stains attached to the wall of the spraying space of the paint sprayer and the paint stains attached to the cylinder and hose to prevent the hose from hardening, and at the same time clean the machine part and the surrounding working environment.

4. Check the contamination of the motor and the oil in the turbine box and the amount of oil once a week, add or replace the oil when necessary.

5. Check the sprocket of the paint sprayer, the lubrication of the chain and whether the chain is tensioned once a week. If there is slack, you can adjust the tension wheel to tighten the chain.

6. Regularly replace the cleaning solvent in the brush box of the paint sprayer, and remove the paint deposited in the box and on the brush.

7. Regularly or frequently remove the oil stains remaining on the conveyor belt of the line paint sprayer.

8. The spray gun should be kept clean and cleaned carefully. Except for failure or replacement of spare parts, do not disassemble the spray gun at will.

9. Don't let the spray gun fall to the ground or be hit by other objects.

10. The nozzle is an important component of the spray gun. It is the key word of the spray gun. The nozzle must be maintained without any damage. It must be cleaned at the end of each operation.

1. When the cleaning nozzle is clogged, metal piercing such as iron wire should not be used. It should be soaked in solvent and then blown with compressed air. Metal brushes cannot be used to clean the nozzle.

12. The nozzle should also be cleaned frequently during the operation, otherwise the paint attached to the nozzle will affect the quality of spraying.

13. Clean up the paint on the paint sprayer in time after use, and recycle the remaining paint.

Finally, it is very important to clean up and maintain the paint sprayer itself.
